Factory Provided ISO9001 RoHS Certificated Aiokingsun Fakra Connector for New Energy Industry

Overview

Basic Info.

Model NO.	AIOKINGSUN FAKRA
Mounting Type	Assemble
Insulating Materials	PTFE
Contact Finish	Gold
Materials	Brass
Standard	Fakra Connector
Interface Type	RF
Shape	Straight
Model No.	Aiokingsun Fakra
Housing Material	PA66+30%GF
Transport Package	Neutral or Customized
Specification	RoHS Materials
Trademark	AIOKINGSUN
Origin	China
HS Code	8536909000
Production Capacity	10000pieces/Week

Product Description

Factory provided ISO9001 RoHS Certificated Aiokingsun Fakra Connector for New Energy Industry

Product Description

FAKRA industry standard compatible connectors are designed to fulfill the rigorous mechanical and environmental requirements of the automotive industry. Ensuring maximum electrical and mechanical performance, these high quality FAKRA connectors feature specific color coded plastic housings in accordance with the FAKRA coding industry standard. Thirteen distinct mechanical and color codes enable easy identification and unique keying to avoid mis-mating and additional one neutral coding. FAKRA connectors are used as standard interfaces for high-frequency telematic applications in vehicles where the number one priority is to ensure safety. For example, in autonomous driving and driver assistance systems where it is necessary to determine exact positioning, continuously calculate routes, and detect and classify objects. High data volumes from several cameras, various sensors and navigation sources must therefore be combined and transmitted in real time.
RF Connector Product Portfolio

• Cable connectors (straight, right angle)
• PCB connectors (pin-in-paste soldering, SMD)
• Panel connectors
• Standardized housings (single, double, triple, quad)
• Cable assemblies
• Customized solutions
• Calibration kits
• measurement equipment & accessories
• Tools
• Waterproof versions

  RF Connector Features

• Impedance 50 Ohm
• Specifications according ISO 20860-1 & US-Car 18
• Frequency range DC up to 6 GHz
• High data rates up to 8 Gbps
• Return loss ≥ 18 dB
• Temperature range from -40 °C to +105 °C
• Mating cycles ≥ 25
• 13 mechanical and colored codings and one neutral coding
• Primary and secondary lock
• Stamped parts on separate coils (center contact, support sleeve, connector head plug

application scenarios

RF Connector Applications

• Radio antenna
• GPS telematics or navigation
• Infotainment & television
• Mobile communication
• RF bluetooth / WLAN applications
• Radio frequency remote control for keyless entry
• Vehicle auxiliary heating
• Sensors for detection, evaluation and reaction

Company Profile

Changzhou Kingsun New Energy Technology Co., Ltd, established in 2010 in Changzhou, China, is an antenna adapter manufacturer specializing in the R&D, design and manufacture of automotive connectors, wiring harnesses, audio equipment accessories, and circular power connectors, etc., as well as providing one-stop solutions for customers. Our products are widely used in the fields of automotive electronics, new energy, medical equipment, intelligent IOT, communication equipment and electrical equipment, etc. In the era of 5G, Changzhou Jinchan will devote itself to the research and development of new fields such as vehicle networking, intelligent driving, human-machine interaction, etc. We will continue to innovate and change, layout cutting-edge technology and leading product development, and provide strong support for advanced solution development. Product quality is the cornerstone and the life of an enterprise. We have a professional quality management team, always uphold the "quality-oriented, customer demand-oriented" management philosophy, with rapid response capabilities, to provide timely quality control support for customers and partners. Our advantages: strict implementation of ISO9001, IATF16949 international quality management system standards, rapid provision of product design solutions and low-cost manufacturing. Our products include: JASO, IEC, DIN, FAKRA, HSD, HSL, SMA, SMB, MCX, N, F, UHF, FME, XLR, DC, M12 and related supporting wires. They all conform to the international technical standards such as JASO, ISO, DIN, IEC-60169-15, MIL-C-39012, etc. Our customers: Hyundai Kia, Ford, FAW, Dongfeng, GM, GAC, SAC, Gillette.

Company business philosophy: integrity, innovation, service, win-win. Focus on the industry, concentrate on doing fine and strong, scientific management, sustainable development, company values: the pursuit of excellence in quality, integrity of customer service, staff to seek common development, create a harmonious society. Social responsibility policy: to be an enterprise respected by society. Adhere to the road of scientific concept of development, conscientiously implement the "Environmental Protection Law". Continuously improve and upgrade, prevent pollution, control harmful substances, rational use of resources, protect the green home, and establish a perfect environmental management system. Everything in the world is connected; both the microcosm and the macrocosm. We are pushing the society forward with the invisible power, linking the world with technology, making the future with service, connecting you and me, warming the world!Certifications

Packaging and Shipping:

FAQ

Q1: Are you a manufacturer?A1: Yes, we are a manufacturer located in Changzhou city of China. We can provide OEM/OOM services for customes around the world.Q2:Can I get a free sample?A2: yes,we can provide the existing items'samples without charge but freight collected. If there is any special samples requirement, please contact us for more details.Q3: How could I pay?A3: We prefer T/T. If you prefer other payment terms,please contact us freelyQ4:the quality of your product guaranteed?A4: Yes, our workshop are equipped with Brand-new and Advanced Machines and Test Equipment. Besides, our worker are Professional Technicians for connector&cable production. Our production process and quality are in strictly accordance with the international standards and customers' requirements. We are warmly welcome your inspection team to examine.Q5: What is the delivery lead time?A5: It depends on the quantity of the purchasing order. The mass production lead time is about 5-10 days after receipt of the deposit
